Rotary table blasting machine built for large and non-tumbling jobs requiring controlled cleaning. Stable rotation delivers accurate blasting coverage and consistent surface finishing quality.
The Airless Shot Blasting Machine – Table Type is designed for heavy, large, and non-tumbling components requiring precise and uniform surface preparation. In this machine, components are placed on a rotating turntable while high-speed blast wheel units project abrasive media onto the surface for consistent and controlled blasting.
This table type shot blasting machine is ideal for jobs that cannot tumble during processing and require stable positioning throughout the blasting cycle.
This type is ideal for:
Smart Process Overview
The component is placed on the rotary table inside the blasting chamber and the front door is securely closed before the cycle starts. The table rotates between 2 to 10 RPM, allowing all exposed surfaces to pass through the blasting zone.
High-speed shot blasting turbine units throw abrasive media such as steel shot or steel grit at high velocity. The abrasive removes rust, scale, and surface contaminants while preparing the component for further processing.
Used abrasive falls into the hopper and is recycled through the screw conveyor, bucket elevator, and air wash separator. Dust is extracted through the integrated dust collector system. After cycle completion, the cleaned component is unloaded
Built With Precision Components
Rotary Table
Heavy-duty fabricated turntable with load capacity ranging from 500 kg to 20 MT.
Blast Wheel Units
10 HP to 30 HP high-efficiency turbines for strong abrasive throwing performance.
Blasting Chamber
Sealed cabinet with manganese steel liners and replaceable wear plates.
Abrasive Circulation System
Includes screw conveyor, bucket elevator, and air wash separator for abrasive recovery.
Dust Collection System
Bag filter or cartridge type dust collector with pulse jet cleaning.
Drive System
Table rotation motor with gearbox and optional VFD speed control.
Electrical Control Panel
PLC or relay-based panel with safety interlocks.
The Airless Shot Blasting Machine – Table Type is best suited for large, heavy, and non-tumbling jobs requiring stable handling during blasting. It ensures precise and uniform blasting results with flexible design options for different component sizes.
Its proven performance in heavy engineering applications makes it a dependable solution for demanding industrial environments.
Explore a wide range of industries where shot blasting plays a critical role in improving surface quality, durability, and production efficiency. From automotive and foundry to fabrication and heavy engineering, Jinil's solutions are designed to meet diverse application needs, ensuring reliable surface preparation, consistent finishing, and optimized performance across demanding industrial environments.
Complete Support Portfolio
The Airless Shot Blasting Machine – Table Type is suitable for blasting heavy and stable components.
Cleaning of heavy fabricated structures
Descaling of large castings
Surface preparation before painting or coating
Rust removal from structural assemblies
Pre-treatment before galvanizing
Cleaning of dies, molds, heavy plates, and engine parts
Operational Performance Benefits
The Airless Shot Blasting Machine – Table Type offers several operational benefits.
Advanced Engineering Highlights
Additional System Enhancements
Optional customization can be provided based on production needs.
Enables easy operation, real-time monitoring, and precise control of blasting parameters for efficient machine performance.
Allows adjustable table rotation speed to ensure optimal blasting exposure and consistent surface cleaning results.
Automates opening and closing of doors for improved safety, faster cycle time, and reduced manual effort.
Removes impurities from abrasive media to maintain consistent blasting quality and extend media life.
Monitors abrasive levels continuously to ensure uninterrupted operation and stable blasting performance.
Automatically maintains required abrasive quantity, reducing downtime and ensuring continuous productivity.
Reduces noise levels during operation, improving workplace comfort and meeting industrial safety standards.
Prevents sparks from entering the dust system while maintaining a clean and safe working environment.
Removes dust and residual abrasive from components after blasting for a clean and ready surface.
Provides visual monitoring of operations for enhanced safety, supervision, and process control.
It is a blasting machine with a rotating turntable designed for cleaning heavy, large, and non-tumbling components using high-speed abrasive projection.
Heavy fabricated parts, large castings, structural assemblies, dies, molds, plates, and engine components are ideal for this machine.
The rotating table ensures all exposed surfaces move through the blasting zone for uniform cleaning and controlled blasting quality.
Common abrasives include steel shot, steel grit, and other suitable blasting media based on the application.
Heavy fabrication, construction equipment, railways, defense, wind energy, and pressure vessel industries commonly use these systems.
Yes, it includes screw conveyors, bucket elevator, and separator for continuous abrasive recovery and reuse
Yes, PLC controls, VFD table speed control, automatic doors, and cycle automation options can be provided.
Yes, options such as heavy-duty tables, extra blast wheels, soundproofing, sensors, and painting line integration are available.
